• Eliminates pre-compaction of bulky material
• Shears off material extending above and/or into the loading chute
• Material is loaded while previous charge is being baled; reduces idling time
• Self-contained, compact design
• No special foundation required
• Minimal field set up
• PLC machine control
• Keyed and bolted construction
• Globally available hydraulic and electronic components
• CE certification available
• Self-cleaning, vertical ejection gate
• Bolted, corrugated, replaceable A-R liner plates
• Density range of 35%-65%
• Built with tough and dependable Nopak cylinders
• Various feed hoppers available
• Completely assembled and tested prior to shipping
• Installation and service personnel available

10DCS

• Bale Size: 12″ x 8″ x Variable
• Bale Weight: 25 Pounds (Aluminum)
• Cycle Time: 50 Seconds
• Output: 72 Bales per Hour
• Power: 25 HP
• Height: 90″
• Width: 90″
• Length: 135″
• Shipping Weight: 13,000 Pounds

10DCSH

• Bale Size: 12″ x 6″ x Variable
• Bale Weight: 25 Pounds (Aluminum)
• Cycle Time: 50 Seconds
• Output: 72 Bales per Hour
• Power: 25 HP
• Height: 90″
• Width: 90″
• Length: 135″
• Shipping Weight: 13,000 Pounds

17DCS

• Bale Size: 12″ x 12″ x Variable
• Bale Weight: 40 Pounds (Aluminum)
• Cycle Time: 50 Seconds
• Output: 72 Bales per Hour
• Power: 50 HP
• Height: 90″
• Width: 125″
• Length: 240″
• Shipping Weight: 29,000 Pounds

40DCS

• Bale Size: 14″ x 14″ x Variable
• Bale Weight: 60 Pounds (Aluminum)
• Cycle Time: 60 Seconds
• Output: 60 Bales per Hour
• Power: 75 HP
• Height: 108″
• Width: 150″
• Length: 276″
• Shipping Weight: 53,000 Pounds

• Touch Screen Operator Panel
• Weigh Hopper with Rear Diverter
• Bulk Hopper with Rear Diverter
• Side Hopper
• High Compression Options

DCS Balers Catalog

Have questions about the Dual Compression Shearing Baler? Send us a note and we'll get back to you as soon as possible!
